• vi
  • IAB 110” 2K

    • Brand: Samsung
    • Screen size: 1.26 mm
    • Resolution: 2560 x 1440 (2K)
    • Brightness: 1,600 nit / 500 nit

    Contact:

    Make greatness out of every meeting

    • Seamless canvas for purer black levels with enhanced depth via Black Seal Technology
    • Spectacular vibrancy for superior color purity to recreate scenes by Ultra Chroma Technology
    • Reinvented installation process by docking and hanging
    • All-inclusive components built-in from control box to speaker

    Adopt a new paradigm for your business

    The Wall is the epitome of innovation. It constantly delivers new avenues to create unparalleled visual statements. Redefining the LED paradigm once again, The Wall now solves the biggest challenge of industry, drastically improving installation. The Wall, let it transform your business.

    Adopt a new paradigm for your business

    An abyss of depth

    Black Seal Technology

    A deep black background blankets the screen with perfect uniformity, creating a seamless canvas for purer black levels with enhanced depth that delivers unparalleled contrast and immaculate detail.

    An abyss of depth

    Superior color purity

    Ultra Chroma Technology

    Colors leap to life with spectacular vibrancy to recreate scenes as if you were there in real life. Narrower wavelengths produce RGB colors two times purer* and more accurate than conventional LEDs.

    * Figure is based on internal testing standards against Samsung’s conventional LED Signage.

    Superior color purity

    The installation process, reinvented

    Pre-assembled Installation

    The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.

    The installation process, reinvented

    * The Wall All-in-One 110-inch model requires three preset modules. The 146-inch model requires four preset modules.
    * Install time estimate based on internal testing.

    The installation process, reinvented

    Pre-assembled Installation

    The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.

    The installation process, reinvented

    * The Wall All-in-One 110-inch model requires three preset modules. The 146-inch model requires four preset modules.
    * Install time estimate based on internal testing.

    The installation process, reinvented

    Pre-assembled Installation

    The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.

    The installation process, reinvented

    * The Wall All-in-One 110-inch model requires three preset modules. The 146-inch model requires four preset modules.
    * Install time estimate based on internal testing.

    The installation process, reinvented

    Pre-assembled Installation

    The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.

    The installation process, reinvented

    * The Wall All-in-One 110-inch model requires three preset modules. The 146-inch model requires four preset modules.
    * Install time estimate based on internal testing.

    Auto configuration setup

    Built-in Control Box

    Time-consuming configuration between control box and cabinet is no longer needed. The Wall All-in-One integrates the control box so it’s built-into the display, eliminating a cumbersome configuration process to get the display up and running faster.

    Auto configuration setup

    Critical decisions without complexity

    Simple Choice

    The Wall All-in-One removes complex elements traditionally associated with LED displays, creating a streamlined purchase path. Now, make purchases based on just two factors – resolution and size – without complications such as pixel pitch or configuration.

    Critical decisions without complexity

    No extra peripherals needed

    All-inclusive Components

    The Wall All-in-One includes everything you need to begin operations – from the control box and wall brackets to speakers and deco bezels. No additional purchases or components are required, allowing you to focus on getting your display up and running fast.

    No extra peripherals needed

    Colors mapped to perfection

    20bit Processing

    The Wall All-in-One offers 20bit processing to present exact color mapping with faultless accuracy. Deeper bit depth at low grayscale also delivers extraordinary contrast ratio and smooth, natural tones.

    Colors mapped to perfection

    Continuous natural shading

    Linear Grayscale

    A precise linear grayscale showcases intricacies in every scene, delivering textures, volume and continuous shadow details. The elevated continuity pulls you further into your content for unbroken immersion.

    Continuous natural shading

    Instant AI optimization

    Neural Quantum Processor 4K

    Every second of content is instantly analyzed and optimized for perfect picture quality. The powerful AI processor delivers superior visuals in any size up to 4K* resolution, enhancing contrast and removing noise.

    Instant AI optimization

    * The upscaling resolution may vary based on the resolution support of individual models.

    Dazzling dynamic range

    MICRO HDR

    Reimagine the limits of conventional screens with advanced picture refinement—HDR10/10+ and LED HDR—to illuminate ideal peak brightness and contrast in every scene for precise, true-to-life imagery.

    Dazzling dynamic range

    Smooth, seamless motion

    MICRO Motion

    Every motion becomes sharper, with greater clarity. The Wall All-in-One automatically converts standard 60Hz signals to 120Hz, removing motion judder in fast-paced action for smoother streams and a seamless viewing experience, every time.

    Smooth, seamless motion

    Physical Parameter

    • Pixel Pitch1.26mm
    • Pixel Configuration1 red, 1 green, 1 blue
    • Configuration (LxH, per cabinet)1920×1080 pixels
    • Diode TypeFlip-chip RGB LED
    • Dimensions (W x H x D, Cabinet)2,419.2×1,360.8×49 mm
    • Diagonal (inch, DiagonalxD, per cabinet)109.3×1.9 inch
    • No. of Modules (WxH, per cabinet)12 x 9
    • Weight (per cabinet/per ㎡)108 kg (TBD)

    Optical Parameter

    • Brightness (Peak/Max)(1)1,600 nit / 500 nit
    • Contrast Ratio(2)24,000 : 1
    • HDR CompatibilityLED HDR / HDR10+ support / AI Picture
    • Viewing angle – Horizontal170°
    • Viewing angle – Vertical155°
    • Bit Depth16 bit (Internal processing 20bit)
    • Color Temperature – Default6,500K ± 500K (Floating bin)
    • Color temperature – Adjustable2,800K ~ 10,000K

    Electrical Parameter

    • Video Rate50/60 Hz 100/120 (FRC) Hz
    • Input Power Range100~240 VAC, 50/60 Hz
    • Power consumption – Max1000 (W/Screen) (TBD)
    • Power consumption – Typical2080 (W/Screen) (TBD)
    • Heat generation – Max(BTU/m², BTU/cabinet)9504 (BTU/Screen) (TBD)
    • Heat generation – Typical(BTU/m², BTU/cabinet)7104 (BTU/Screen) (TBD)
    • Refresh rate3,840 Hz
    • Power RedundancyNo

    Operation Conditions

    • Working Temperature / Humidity0℃~+40℃ / 10%~80%RH
    • Storage Temperature / Humidity-20℃~+45℃ / 5%~95%RH
    • IP RatingIP20
    • LED Lifetime150,000 hours

    Connectivity

    • ControllerBuilt-in

    Features

    • MagicINFOYes
    • SensorTemperature, Eco Sensor
    • Operating SystemTizen 6.5

    Certification

    • Safety62368-1, 60950-1
    • EMCClass A
    • Eye-protectionTUV Low Blue Light

    Service

    • ServiceFront

    Package

    • Box Dimension (WxDxH)TBD
    • Package Weight (kg, per cabinet)148 kg

    Special Installation

    • OtherSide by Side Installation with additional frame kit (up to 4 screens)

    Accessories

    • AccessoriesDécor Frame, Frame Kit, Buffer parts (12 Modules, 1 T-Con, 1 SMPS)
    • Remote ControlIR Remote Cotroller

    Disclaimer

    • Disclaimer(1)Peak value according to IDMS (Information Display Measurement Standard)
    • Disclaimer(2)Measured under 10lux light Test condition. Contrast in darkroom exceeds 1000000:1
    • Disclaimer(3)Referring to visual refresh rate
    • Disclaimer(4)optional structure required
